Bulk-fuel equipment storage.
A modular crate for bulk-fuel equipment that stacks up to four high on a common footprint and moves in tandem.
WRM Cuberpayload (crate 12,000 lb UDL)
stacks on 1 footprint
WRM44 / 62 / 83 / 100
common footprint (2,997 × 2,438 mm)
Purpose-built for deployment.
Why it’s differentRead moreShow less
Four heights share a common 118 × 96 in (2,997 × 2,438 mm) footprint so mixed loads stack compatibly, and each crate can hold equipment up to 10,000 lb.
Bulk Fuel Cuber densifies storage of bulk-fuel and DABS equipment sets, keeping heavy assemblies stacked, secured and mobile within a warehouse or yard.
Engineered, calculated and proof-tested.
How it’s builtRead moreShow less
It stacks up to four high, integrates with mobile bases, and is finished in paint or hot-dip galvanizing.
Configurations: BABFEC44 / 62 / 83 / 100; mobile bases; quick-release bars; tie-down points; optional fixed sides.
Engineered in from the start.
Capabilities- Equipment sets, together
- Mixed-height stacking
- Warehouse or yard
- Moves in tandem
The engineering envelope.
Specifications- Crate max UDL
- 12,000 lb (5,440 kg)
- Payload
- up to 10,000 lb (4,536 kg)
- Stacking
- up to 4 high
- Footprint (common)
- 118 × 96 in (2,997 × 2,438 mm)
- Heights
- four — BABFEC44 / 62 / 83 / 100, 56 - 116 in overall
- Steel
- powder-coated or hot-dip galvanized
